Bundling harness
Bare conductor with insulation
The conductor material can be AAC, AAAC, ACSR, ACAR, CCA, etc.
It consists of a set of insulated phase and neutral conductors that are tightly bundled together to form a single unit.
The conductors of BC overhead cables are separated by insulation layers to reduce the risk of short circuits.
Usually by connecting conductors to overhead support structures (such as power poles, cable beams, etc.)
Introduction
ABC aerial cable (Aerial Bundled Cable) is an overhead cable system used for power transmission. It consists of a set of insulated phase and neutral conductors that are tightly bundled together to form a single unit. The phase conductors are used to transmit power, while the neutral conductor is used to provide power balancing and return of fault currents.
Application
Urban or rural power grids: ABC overhead cables can be used on low-voltage and medium-voltage transmission lines in power distribution networks. They can be installed on support structures such as power poles, suspension lines, cable beams, etc., and are used to transmit electrical energy from substations to power consumption terminals such as residential, commercial and industrial areas.
Mountainous and remote areas: ABC overhead cables play an important role in power transmission in mountainous and remote areas. Due to factors such as complex terrain and inconvenient transportation, the cost of traditional underground cable laying is relatively high. ABC overhead cables can be installed overhead, which is more cost-effective and efficient.
Specification
| Product name | ABC OVERHEAD CABLE |
| Brand Name | HONGLIN |
| Model Number | 1~5 Cores |
| Application | overhead power tramsmission |
| Brand | HONGLIN |
| Conductor | Aluminum Conductor |
| OEM | Accept |
| Packing | Wooden Drum etc. |
Standards
IEC 60502-1 and IEC 60502-2 are the most widely used power cable standards in the world.
Chinese National Standard GB/T 12527-2008
Component composition
Packaging: wooden barrel
Goods: finished product + wooden barrel packaging
Certification
Manufacturing process
There are nine steps in the low-voltage power cable production process：stranding machine; extrud; cooling; diameter measurement; Bearing winch; Set meter counter; testing; Spark test; packing
Payment Method
T/T; L/C ; Western Union
