Aerial Insulated Cable
Scan the QR code
It has the main characteristics of high power supply reliability, good power supply security, convenient erection and maintenance, and reasonable economy.
Its main technical parameters include weather resistance, insulation level, inner and outer semi-conductive shielding layers. Overhead cables are widely used in power transmission at home and abroad.
Introduction
Aerial cables are overhead conductors equipped with an insulating layer and a protective sheath. They are a special cable manufactured using a production process similar to cross-linked cables. They are a new power transmission method between overhead conductors and underground cables. Aerial cables are all single-core. According to their different structures, they can be divided into hard aluminum wire structures, hard-drawn copper wire structures, aluminum alloy wire structures, steel core or aluminum alloy core support structures and self-supporting three-core textured structures (wire structures). The core can be hard aluminum or hard copper wire), etc.
Application
Overhead insulated cables have the advantages of strong resistance to electrical breakdown, good insulation, and fewer joints. Therefore, they are often used as high-voltage and large-capacity cables in power transmission systems to meet the needs of power transmission.
In areas such as cities and traffic arteries, where underground space is tight or the road surface cannot be opened, overhead cables are needed for power transmission. The application of overhead insulated cables can greatly reduce maintenance costs and reduce failure rates.
Some equipment in industrial and mining enterprises require the supply of large amounts of electric energy. If traditional cable systems are used, they will be subject to some restrictions. The use of overhead insulated cables can solve these problems and ensure the normal operation of the equipment.
In architectural lighting systems, overhead insulated cables are often used because the buildings are tall and the transmission distance is large.
Specification
| Product name | ABC OVERHEAD CABLE |
| Brand Name | HONGLIN |
| Model Number | 1~5 Cores |
| Application | overhead power tramsmission |
| Brand | HONGLIN |
| Conductor | Aluminum Conductor |
| OEM | Accept |
| Packing | Wooden Drum etc. |
Component composition
Packaging: wooden barrel
Goods: finished product + wooden barrel packaging
Certification
Manufacturing process
There are nine steps in the low-voltage power cable production process：stranding machine; extrud; cooling; diameter measurement; Bearing winch; Set meter counter; testing; Spark test; packing
Payment Method
T/T; L/C ; Western Union
Certification
