PVC Insulation Copper wire BV/BVR/BVV/BVVB
Scan the QR code
BVVB wire, also known as flat twin and earth cable.
Space-saving design: BVVB wire consists of two insulated conductors (twin) and an additional uninsulated conductor (earth) laid flat side by side. This design allows for a compact and space-saving installation.
Easy installation: Makes it easier to handle and install compared to round cables.The flat shape also helps to minimize the risk of cable twisting or tangling during installation.
Versatility and Cost-effective
Compatibility with accessories: BVVB wire is compatible with a wide range of electrical accessories, such as switches, sockets, and junction boxes.
Introduction
BVVB wire, also known as flat twin and earth cable, is a type of electrical wire commonly used for domestic wiring applications. It is similar to KVV wire but has some distinct characteristics.
Application
BVVB wire, also known as flat twisted pair and ground cable, is commonly used in a variety of electrical wiring applications in residential, commercial, and light industrial environments.
In residences, BVVB wire is commonly used in general lighting circuits, as well as in electrical outlets, switches, and other electrical equipment. The flat design of BVVB wires makes them suitable for hidden wiring in walls, ceilings and under floors.
In commercial buildings, it is used for wiring lighting systems, electrical outlets, HVAC (heating, ventilation and air conditioning) equipment and other electrical infrastructure.
In light industrial applications, it can be used to power machinery, equipment and control systems in small industrial environments.
BVVB wire is frequently used in renovation and renovation projects to update or expand existing electrical systems. Its low profile design and flexibility make it easier to install in existing conduits, pipes and other wiring paths.
Specification
| Type | Size | Conductor Diameter | ConductorDiameter | ConductoDiameter | Overall Diameter | Current Value |
| mm2 | mm | mm | mm | mm | A | |
| BVVBTwoCores | 2X0.75 | 0.97/1*2 | 0.37/7*2 | 0.20 /23*2 | 3.9*6.1 | 6 |
| 2X1.0 | 1.13 / 1*2 | 0.43/ 7*2 | 0.20 /30*2 | 4.1*6.4 | 9 | |
| 2X1.5 | 1.38/1*2 | 0.52 /7*2 | 0.20/ 48*2 | 4.5*7.3 | 18 | |
| 2X2.5 | 1.78/1*2 | 0.68 / 7*2 | 0.20 / 78*2 | 5.3*8.7 | 26 | |
| 2X4 | 2.25 / 1*2 | 0.85/7*2 | 0.25/80*2 | 5.8*9.7 | 38 | |
| 2X6 | 2.76 / 1*2 | 1.04 / 7*2 | 0.30/ 84*2 | 6.5*10.9 | 44 | |
| 2X10 | 3.58 / 1*2 | 1.35 / 7*2 | 0.40/80*2 | 8.4*14.5 | 68 | |
| BVVBThree Cores | 3X0.75 | 0.97/1*3 | 0.37/7*3 | 0.15 /23*3 | 3.9*8.3 | 6 |
| 3X1.0 | 1.13 / 1*3 | 0.43/ 7*3 | 0.20 /30*3 | 4.1*8.7 | 9 | |
| 3X1.5 | 1.38/1*3 | 0.52 /7*3 | 0.20/ 48*3 | 4.5*10.1 | 18 | |
| 3X2.5 | 1.78/1*3 | 0.68 / 7*3 | 0.20 / 78*3 | 5.3*12.1 | 26 | |
| 3X4 | 2.25 / 1*3 | 0.85/7*3 | 0.25/80*3 | 6.0*13.7 | 38 | |
| 3X6 | 2.76 / 1*3 | 1.04 / 7*3 | 0.30/ 84*3 | 6.5*15.2 | 44 | |
| 3X10 | 3.58 / 1*3 | 1.35 / 7*3 | 0.40/80*3 | 8.4*20.5 | 68 |
Component composition
Packaging: wooden barrel
Goods: finished product + wooden barrel packaging
Certification
Manufacturing process
There are nine steps in the low-voltage power cable production process：stranding machine; extrud; cooling; diameter measurement; Bearing winch; Set meter counter; testing; Spark test; packing
Payment Method
T/T; L/C ; Western Union
